The Avenue empowers you to go farther and faster.
The state-of-the-art watt motor achieves an ideal balance between power and efficiency. The high-tech battery is both lightweight and long-lasting. Together, they set the standard for real-world performance.
PEDEGO E-BIKES ARE MADE TO LAST
Pedego is a fun company, but we’re serious about quality.
Premium quality is more than just a talking point at Pedego, it’s a promise.
It’s a promise that’s backed up by an exclusive five year warranty. That’s quality that lasts!
SMALL DETAILS MAKE A BIG DIFFERENCE
Every Pedego is lovingly designed in California with you in mind. They are crafted with select, premium quality components from the ground up.
Small details make a big difference, and when you ride a Pedego, you can tell that we really care.
Key Features
PedalSense®
5 levels of pedal assist and LCD Display.
Adjustable Handlebars
Adjustable handlebar stem allows you to find a perfect fit.
Sturdy Wheels
Double wall wheels with heavy-duty spokes or upgraded Mag Wheels.
Integrated Battery
A removable battery is integrated into the frame for sporty handling.
Quality Components
Disc brakes, seven gears, sturdy kickstand, heavy-duty spokes, and more.
Throttle
Twist & go throttle for full power on demand.
Optional Upgrades
Front headlight, rear tail light, fender set, rear rack, front rack, and front suspension fork available.
- MOTOR
BLACK 48V BRUSHLESS GEARED REAR HUB MOTOR; 500 WATT NOMINAL POWER RATING; 45NM NOMINAL TORQUE RATING / 60NM MAX TORQUE; QUICK DISCONNECT CABLE W/ WATERPROOF CONNECTION.
. - BATTERY
48V/10AH OR 48V/14AH BATTERY W/ PREMIUM LG, PANASONIC OR SAMSUNG LI-ION CELLS.
- CHARGER
48V 2A FANLESS SMART CHARGER WITH CHARGE INDICATOR LIGHT.
- CONTROLLER
48V/18A SINE WAVE CONTROLLER W/ CUSTOM PEDALSENSE® SOFTWARE AND WATERPROOF CONNECTIONS.
- THROTTLE
TWIST AND GO THROTTLE W/ THREADED WATERPROOF CONNECTION.
- PEDALSENSE®
FREE RIDE MODE (NO POWER), FIVE LEVELS OF PEDAL ASSIST W/ THROTTLE OVERRIDE & THROTTLE ONLY MODE.
- TOP SPEED
32 KM/H WITH MOTOR ASSISTANCE ONLY
- DISPLAY
2.5” BACKLIT LCD SCREEN; 3 BUTTONS TO CONTROL ELECTRONICS, TOGGLE INFO DISPLAYED, AND CUSTOMIZE SETTINGS; USB CHARGING PORT; WATERPROOF THREADED CONNECTION; CUSTOM PEDALSENSE® SOFTWARE.
- DERAILLEUR
MICROSHIFT RD-M26L 7-SPEED; RESIN BODY W/ ENGINEERING COMPOSITE PULLEYS.
- CASSETTE
SHIMANO HYPERGLIDE HG20 7 SPEED 12-32T; SMOOTH, LIGHT & RELIABLE SHIFTING PERFORMANCE.
- SHIFTER
MICROSHIFT TS71-7R RIGHT HAND THUMB-TAP SHIFTER W/ OPTICAL GEAR DISPLAY.
- BOTTOM BRACKET
68MM X 127.5MM SQUARE TAPER SPINDLE W/ SEALED CARTRIDGE BEARINGS; STEEL CUPS & BODY.
- CHAIN
SHIMANO HG40 1/2”X3/32” 122 LINKS.
- CRANKSET
BLACK 3 PIECE CRANK W/ 5X130MM 45T 3/32” STEEL CHAINRING; 170MM FORGED ALUMINUM CRANK ARMS.
. - PEDALS
WELLGO COMPOSITE PLATFORM PEDAL; 9/16” SPINDLE; INTEGRATED PEDAL REFLECTORS.
- FRAME
28” 6061-T6 ALUMINUM ALLOY; INTEGRATED DOWNTUBE BATTERY; SEMI-INTERNAL CABLE ROUTING.
. - FORK
28” RIGID FORK W/ ALUMINUM LEGS; 1 1⁄8” THREADLESS STEERER TUBE; DISC BRAKE, FENDER & FRONT RACK MOUNTS.
- HEADSET
ZERO STACK SEMI-INTEGRATED 1 1⁄8” THREADLESS; ZS44/28.6 | ZS56/40.
- SEATPOST
BLACK ALUMINUM ALLOY RIGID SEATPOST 27.2MM X 350MM.
. - SADDLE
SPORT STYLE SADDLE W/ SINGLE DENSITY FOAM & CENTER CHANNEL RELIEF; CHROMOLY RAILS; 270MM L X 144MM W.
- RIMS
LIGHTWEIGHT ALUMINUM ALLOY DOUBLE WALL RIMS; 3D ANGLE DRILLED SPOKE HOLES; 12G X 36 HOLE.
- SPOKES
BLACK HEAVY DUTY 12G FRONT & REAR STAINLESS STEEL SPOKES W/ BRASS NIPPLES.
- GRIPS
BLACK CLASSIC MUSHROOM STYLE RIBBED RUBBER GRIPS; CUSTOM PEDEGO DESIGN.
- HANDLEBAR
BLACK MTB RISER; ALUMINUM ALLOY; 31.8MM STEM CLAMP DIAMETER; 30MM RISE; 720MM WIDTH.
- STEM
BLACK ALUMINUM ALLOY W/ ADJUSTABLE ; 90MM LENGTH; 31.8MM HANDLEBAR CLAMP DIAMETER; 1 1⁄8 (28.6MM) THREADLESS STEERER TUBE CLAMP DIAMETER.
- TIRES
CST ZEPPELIN 28” X 2.0” OR VEE MALIBU 28” X 2.15”, PUNCTURE RESISTANT + SIDEWALL REFLECTIVE STRIP; SCHRADER VALVE.
- BIKE (NO BATTERY)
AVENUE CLASSIC 28”: 44.6 LB; AVENUE STEP THRU 28”: 45 LB.
- BATTERY
48V/10AH: 6.4LB; 48V/14AH: 7.8 LB.
Note:
The Avenue model qualifies for the Pedego Care 5-Year warranty.
Warranty Requirements:
- Proof of purchase
- Registration at the time of purchase
- 160km tune up by an authorized Pedego dealer
- Annual service by an authorized Pedego dealer
This warranty extends from the date of purchase, is offered only to the original retail purchaser, and is not transferable.
